45º Universal Head
- Country of Origin:Taiwan
- Model:KS-U45 Series
- Minimum Order:1 Set
- Delivery Lead Time:30~60 DAYS
- Delivery FOB Port:FOB Taichung Port
- Payment Condition:T/T or Western Union
Detail Specifications
Model: KS-U45
Max. speed: 2000rpm
U/D: U/D
Flange diameter: Φ250/Φ300mm
Connector: F
Tool arbor with/without spring: H1/H2
Spindle taper: ISO 50#
Gear ratio: 1:1
Outside diameter: Φ128.5mm
Max. cutter diameter: Φ200mm
Weight: 85kgs
